Checking the charge level of the internal batteries and the Li-35 accessory battery pack

You can check the charge level of the internal batteries and the user-replaceable Li-35 accessory battery pack (if installed) from the Status bar (top right corner of the screen).

If there is no Li-35 accessory battery in the device, only one battery icon is shown. If an LI-35 accessory battery is installed correctly, a second battery icon with a small circle in its lower right corner is also shown:

If Battery percentage is turned on, each battery icon also shows the battery charge level on the Status bar as a percentage.

See Using the Battery settings app, page 1 for more information on turning on Battery percentage.

To access the detailed battery charge information for the internal batteries and the Li-35 accessory battery pack, swipe down from the top of the display, tap the Settings icon, then tap Battery. See Using the Battery settings app, page 1 for more information.

To check the battery status of the accessory battery pack when it is not installed in the device, see Checking the charge level of the Li-35 accessory battery pack using the battery indicator.
